The 3.1mm diameter HYF-XP enables easy, safe insertion without cervical dilation or anaesthesia, and provides a 10% larger field of view, to ease intra-uterine pathology diagnosis. The 3.1mm diameter flexible hysteroscope offers higher imaging capability and greater flexibility, while assuring patients minimal trauma and faster recovery time. The slimmest hysteroscope in its class, it enables easy, safe insertion without cervical dilation or anaesthesia, and advanced lens and fibre technologies enable a 10% larger field of view, to ease intra-uterine pathology diagnosis.

• Key Benifits

  No anaesthesia or cervical dilation required

  3.1mm outer diameter allows easy, safe outpatient uterine cavity exploration, without anaesthesia or cervical dilation.

  Angulation of 100° up and down

  Wide, short-scale angulation enables ease of movement within the uterus, without fear of damaging the uterine wall.

  Suitable for minor therapeutic procedures

  The 1.2mm irrigation channel allows for minor therapeutic procedures such as biopsies.

• Product Details

  3.1mm diameter

  The best compromise between patient comfort and optical image quality; the accepted standard for office procedures.
  Because, in almost all cases, no cervical dilation is required, no local anaesthesia is necessary.

  10% larger field of view

  Enables panoramic inspection of entire uterine cavity (fundus + both tubal orifices) without any movement of the instrument.

  Horizontal angulation

  The distal tip angulation of 100° has been specifically designed for the horizontal plane, so that left or right lever movements result in corresponding left or right angulation, for inspecting the tubal ostia.

  Short bending section

  Because the uterus has many cramped spaces, a bending section that angulates within a small radius is desirable, in order to enable maneuverability and to prevent damage to the endometrium.

• Specifications

  Mechanics	Outer diameter of distal end	3.0 mm
  	Outer diameter of insertion tube	3.1 mm
  	Working length	230 mm
  	Total length	540 mm
  	Channel size	1.2 mm
  	Light guide	integrated
  	Angulation plane	horizontal
  	Angulation range	up/down 100°
  Optics	Field of view	100°
  	Depth of field	2.4 - 50 mm

• Compatibility
  •

    VISERA ELITE Xenon Light SourceCLV-S190



    Brighter, more powerful Narrow Band Imaging
    Photo Dynamic Diagnosis

    Brochure
  •

    VISERA ELITE Video ProcessorOTV-S190

    Ground- breaking resolving power for safe procedure
    Brighter, more powerful NBI
    Outstanding, true-to-life image quality

    Brochure
  •

    Full HD 3CCD Camera HeadCH-S190-XZ-E/Q



    Full HD 3CCD
    Power Zoom
    Power Focus

    Brochure
