Olympus offers a wide range of snares in various shapes and sizes to suit our customers' needs and preferences, including softer, thinner wire snares that ensure a sharper cut, as well as firmer wire snares that make it easy to capture lesions.

• Key Benifits

  Reusable electrosurgical snare

  All Olympus reusable snares consist of a snare wire, a snare sheath and a snare handle. One of the most successful models is the SD-5U-1, this snare consists of MAJ-219 (snare sheath), MAJ-218 (snare wire) + MH-264 (snare handle). It features a crescent loop shape, a working-length of 2300mm, a loop-diameter of 22 mm and a wire-diameter of 0,4 mm.

• Product Details
  • Thin pliant wire design
  • SD-7P-1: crescent shape ideal for EMRC
  • SD-7C-1, -18C-1: for debulking pulmonary tumours
  • Outer plastic sheath to be combined with snare wire and SD handle (MH-264)
• Specifications

  Article name	Component of	Article number	Quantity	Min. working  channel Ø	Working length	Wire ø	Loop ø (A)	For use with	Area compatibility
  MAJ-377	SD-7C, 18C-1	028226	1 sheath	2.0 mm	1050 mm	-	-	MAJ-557 or MAJ-378, MH-264
  MAJ-557	SD-7C-1	026971	1 wire	2.0 mm	1050 mm	0.3 mm	23 mm	MAJ-377, MH-264
  MAJ-378	SD-18C-1	028227	1 wire	2.0 mm	1050 mm	0.3 mm	13 mm	MAJ-377, MH-264
  MAJ-10	SD-7P-1	026000	1 sheath	2.0 mm	1900 mm	-	-	MAJ-11, MH-264
  MAJ-11	SD-7P-1	026001	1 wire	2.0 mm	1900 mm	0.3 mm	23 mm	MAJ-10, MH-264
  MH-264	-	027004	1 handle	-	-	-	-	SD-7C-1, -18C-1, -7P-1	-



  MH-264


  •
